Product Details:
|
| Lamp Power(w): | 18W,24W,30W,40W,50W | Input Voltage(v): | 100-277C,VAC/DC24-48V |
|---|---|---|---|
| Ip Rating: | IP66 | Color Temperature(cct): | 2700-6500K |
| Application: | Oil &gas ,hazardous Location, Refinery | Warranty: | 5 Years |
Features:
Application:
Pharmaceutical Plant
Parameters:
| Electronical & photometric parameters | |
| Luminaire Efficacy: | 110lm/W |
| Lifespan: | >50,000 hours |
| Operating Voltage: | 12 VAC/DC |
| 24 VAC/DC | |
| 36 VAC/DC | |
| 48 VAC/DC | |
| Power(W): | 18/24/30/40/50 |
| Frequency: | 50/60Hz |
| Power Factor: | ＞0.9 |
| THD: | ＜15% |
| Insulation Class: | Ⅰ |
| LED Driver: | Over voltage protection |
| short circuit protection | |
Mechanical Features:
| TYPE | Portable | Stanchion portable |
| Weight: | 3.1Kg | 3.3Kg |
| Size: | 218.9*404.5mm | 260 .9 *406 .5 mm |
| Ambient Temperature: | -20℃-+55℃ | |
| Connecting Terminals: | 3*1.0-2.5mm²(L+N+PE) | |
| Available cable : | Outer diameter φ7-φ12mm | |
| Cable Entries: | NPT3/4 | |
| Earthing Protection: | M4 (Internal & external earth bolts) | |
| IP Code: | IP66 | |
| Enclosure Material: | ADC12+glass+SUS304 | |
| Enclosure Colour: | Yellow RAL1026(optional Grey RAL7040) | |
| Coating: | Epoxy powder coating | |
| Exposed Fastener: | Stainless steel | |
| Protective Cover: | Tempered glass,Stand 4J impact | |
