Product Details:
|
| Light Source: | LED | Ip Rating: | IP66/IP67 |
|---|---|---|---|
| Item Type: | Explosion Proof Lights | Application: | Gas Station, Chemical Industry, Factory, Gas/chemical Industry, Platform |
| Warranty: | 5 Years | Material: | Copper-free Aluminum |
| High Light: | 2200K IP67 Explosion Proof LED Lights,IP67 Explosion Proof LED Lights 2200K,2200K 150W ex proof light |
||
Led Ul Certificate 844 Ip67-Explosion Drop Fitting As Ab 50 Ev35 Explosion Proof Light High Temperature light
Venas High Temperature High Bay Light, which is applied to ambient high temperature working area where operation temperature may reach 158℉(70°C), such as steel plant, aluminum smelter, and other high-temperature, dust, corrosive gas environment.
The HB Series high heat resistant lights combine optical performance energy efficiency and outstanding versatility to meet the requirements of high temperature lighting applications in high-temperature, dust, corrosive gas environment, delivering a wide range of light outputs. The enclosure body is made of aluminum with corrosion-resistant coating which protects against overheating damage.
| Model | HB-xxxW-D1YZDG | HB-xxxW-D2YZDG | HB-xxxW-D4YZDG |
| Power | 10-150W | 100-300W | 300-600W |
| Voltage | AC127-270V/AC347-480V,50/60Hz | ||
| Efficiency | 150Im/W | ||
| CRI | >70 | ||
| Beam Angle | 20°-120° | ||
| CCT | 2200k-7000k | ||
| Amebient Temperature | 40℉ to + 158℉(-40℃ to +70℃) | ||
| IP Rating | IP66/IP67 | ||
| IK | IK09 | ||
| LED Chip | 5050/3535/3030 | ||
| Model | Quantity/Carton | Packing Size(mm) | N.W(KG) | G.W(KG) |
| HB-xxxW-D1YZDG | 1 | 340*340*550 | 8 | 9 |
| HB-xxxW-D2YZDG | 1 | 380*670*306 | 16 | 17 |
| HB-xxxW-D4YZDG | 1 | 696*675*306 | 32.25 | 33.25 |
Unit:mm or inch
HB-xxxWD1
HB-xxxWD4
No.1 Hook Pendant Mounting
No.2 Bracket Mounting
