Product Details:
|
| Material: | Copper-free Aluminum | Power: | 20,30,40,50,60 |
|---|---|---|---|
| Item Type: | Explosion- Proof Lights | Color Temperature(cct): | Pure White, Cool White ,warm White |
| Ip Rating: | 66 | Input Voltage(v): | AC100-277V/ 200-480V |
| High Light: | 2200K 60W explosion proof led flood light,2200K 50W explosion proof led flood light,2200K 20W explosion proof led fixtures |
||
High Quality atex Led Explosion Proof Lighting Professional Explosion Proof flood light Explosion-proof Lights R
ATEX Marking:
II 2 G Ex db eb mb IIC T5/T6 Gb
II 2 D Ex tb IIIC T95°C/T85°C Db IP66
IECEx Marking:
Ex db eb mb IIC T5/T6 Gb
Ex tb IIIC T95°C/T85°C Db
UL844 Marking (North American):
Class I, Division 2, Groups A, B, C, D
Class II, Division 1, Groups E, F, G
Class II, Division 2, Groups F, G
Class III
Marine Marking:
UL 1598
UL 844
Ambient Temperature:
Normal: -40°C to 45°C/60°C (-40°F to 113°F/140°F)
Emergency: -10°C to 45°C/60°C (14°F to 113°F/140°F)
IP66
Oil and gas industry
• All petroleum production and refining
• Petroleum loading and transportation
• Petroleum storage and retail
• LNG industry
• All mining operations and service
Ocean, marine and aerospace field
• Ocean platform operation facilities
• Aerospace clean room and production
• Ocean vessel operations
Food and alcohol industry
• Flour and fine particle production and storage
• Food and distilling production
• Alcohol industry
Chemical industry
• All types of paint facilities
• Chemical production and storage
Metal treatment
• Steel and aluminum factories
• Pumping stations in any environment
• Metal smelting, foundry and fabrication
Other high humidity, high dust, high temperature, vapor locations.
Backup battery is optional.
AC or DC power supply is available.
Stainless-steel body and PC cover.
Heavy-duty and high impact resistance.
High-quality SMT LED and Meanwell driver.
Water-proof, vapor-proof, dust-proof, and corrosion resistant.
5-year warranty.
Technical Data:
| Model | Wattage | Operating Voltage | Efficacy(Im/W) | Total Lumens(Im) | CRI | CCT |
| EX-20W R2YZDA | 2*10W/2ft | AC100-277/220-480V | 140 | 2800 | >70 | 2200K-7000K |
| EX-30W R2YZDA | 2*15W/2ft | AC100-277/220-480V | 140 | 4200 | >70 | 2200K-7000K |
| EX-40W R4YZDA | 2*20W/4ft | AC100-277/220-480V | 140 | 5600 | >70 | 2200K-7000K |
| EX-50W R4YZDA | 2*25W/4ft | AC100-277/220-480V | 140 | 7000 | >70 | 2200K-7000K |
| EX-60W R4YZDA | 2*30W/4ft | AC100-277/220-480V | 140 | 8400 | >70 | 2200K-7000K |
R2
R4
| Model | Quantity/Carton | Packing Size | Net Weight(kg) | Gross Weight(kg) |
| R2 | 1 PCS | 32.28*9.84*7.09 | 4 | 5 |
| R4 | 1 PCS | 51.97*8.66*7.09 | 8 | 10.7 |
Rope Mounting:
Ceiling Mounting:
Ceiling Mounting:
FAQ
Q1. Can I have a sample order ?
Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for order?
Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order ?
Firstly, let us know your requirements or application.
Secondly, We quote according to your requirements or our suggestions.
Thirdly,customer confirms the samples and places deposit for formal order.
Fourthly, We arrange the production.
