Product Details:
|
| Material: | Copper-free Aluminum | Item Type: | Explosion- Proof Lights |
|---|---|---|---|
| Working Lifetime(hour): | 50000 | Warranty: | 5 Years |
| Lamp Power(w): | 20,40,60,80,100,150,200,250,280 | Working Temperature(℃): | -40 - 60 ; -40 - 80 |
| High Light: | Class I Division 1 Explosion Proof LED Lights,Explosion Proof LED Lights High Impact Resistance,20W class 1 div 1 light fixtures |
||
New Arrival Led Explosion Proof Light Class I Division 1 High Impact Resistance 5 Years Warranty For Chemical Hazardous
Marking ATEX
Il2 G Ex db IIB T5/T6 Gb
Il2 D Ex tb IIIC T80/90C Db IP66
Marking IECEx
Ex db IIB T5/T6 Gb
Ex tb IIIC T80/90C Db IP66
Marking UL844 (North American)
Class I, Division 1, Groups C, D
Class I, Division 2, Groups A,B,C,D
Class II, Division 1, Groups E,F,G
Class II, Division 2, Groups F, G
Class III
Marine Marking
UL 1598
UL1598A
ABS
IP66
Housing: Copper-free aluminum
Lens: Tempered glass
Hardware: Stainless steel
Mounting Bracket: Stainless steel
Emergency battery backup is available.
5-year warranty.
Working Temperature: -40°C to 60°C (-40°F to 140°F); ATEX & IECEx (IC solution): -40°C to 80°C (-40°F to 176°F).
| Model | Wattage | Operating Voltage | Lumens(Im) | Efficacy(Im/W) | CRI | CCT | Emergency Time |
| EX-20W C2YZDA | 20W | AC100-277V/DC12-48V,AC200-480V | 2800 | 140 | >70 | 2200K-7000K | 3 hours |
| EX-40W C2YZDA | 40W | 5600 | |||||
| EX-60W C2YZDA | 60W | 8400 | |||||
| EX-80W C2YZDA | 80W | 11200 | |||||
| EX-100W CYZDA | 100W | 14000 | |||||
| EX-150W CYZDA | 150W | 21000 | |||||
| EX-200W C3YZDA | 200W | 28000 | |||||
| EX-250W C3YZDA | 250W | 35000 | |||||
| EX-280W C3YZDA | 280W | 39200 |
| Model | Quantity/Carton | Packing Size | Net Weight(kg) | Gross Weight(kg) |
| C2 | 1 PCS | 18.50x18.50x13.58inch | 14 | 16 |
| C | 1 PCS | 21.65x20.47x14.17inch | 17.4 | 19 |
| C3 | 1 PCS | 21.85x21.85x13.58inch | 21 | 25 |
Oil and gas industry
• All petroleum production and refining
• Petroleum loading and transportation
• Petroleum storage and retail
• LNG industry
• All mining operations and service
Ocean, marine and aerospace field
• Ocean platform operation facilities
• Aerospace clean room and production
• Ocean vessel operations
Food and alcohol industry
• Flour and fine particle production and storage
• Food and distilling production
• Alcohol industry
Chemical industry
• All types of paint facilities
• Chemical production and storage
Metal treatment
• Steel and aluminum factories
• Pumping stations in any environment
• Metal smelting, foundry and fabrication
Other high humidity, high dust, high temperature, vapor locations.
Q1. What about the lead time?
A: 3-5 days for Sample preparing ,8-10 working days for mass production.
Q2. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available.
