Product Details:
|
| Material: | Copper-free Aluminum | Item Type: | Explosion- Proof Lights |
|---|---|---|---|
| Ip Rating: | 66 | Input Voltage(v): | AC100-277V/DC36V |
| Cri (ra>): | 70 | Color Temperature(cct): | 2700k-6500k |
| High Light: | 80W Explosion Proof LED Lights,ATEX Explosion Proof LED Lights,IP66 explosion proof led flood light |
||
ATEX Certified 20~80W Anti-Explosion Proof Lamp Chemical Industry Ip66 Led Explosion Proof Lights
EN-60079: II2 G Ex op is eb mb IIC T5/T6 Gb
II2 D Ex op is tb IIIC T95/80 Db
EN 60079-0 EN-60079-31 EN-60079-18
IP66
IK10
Ambient Temperature: T6: -20℃ to 40℃ (-4℉ to 104℉)
T5: -40℃ to 60℃ (-40℉ to 140℉)
0-10V dimming.
Beam angles are optional form 40°, 60° and 90°.
Best-in-class efficacy is up to 130 lumens per watt.
Great impact resistance with IK10 certified.
Professional light distribution design delivers uniform and comfortable lighting.
Housing: Die-cast aluminum and A6061
Cover: Fireproof transparent PC
| Model | Wattage | Operating Voltage | Total Lumens(Im) | Efficacy(Im/W) | CRI | CCT | Dimming |
| EX-xxxW FLC2 AZDA | 20w/40w | AC100-277V or DC36V | 2600/5200 | 130 | >70 | 2700K-6500K | 0-10V |
| EX-xxxW FLC4 AZDA | 50w/80w | AC100-277V or DC36V | 6500/10400 | 130 | >70 | 2700K-6500K | 0-10V |
| EX-xxxW FLC5 AZDA | 50w/80w | AC100-277V or DC36V | 6500/10400 | 130 | >70 | 2700K-6500K | 0-10V |
| Model | Quantity/Carton | Packing Size | Net Weight(kg) | Gross Weight(kg) |
| EX-xxxW FLC2 AZDA | 1 PCS | 6.30*9.21*53.94 | 7.5 | 9.5 |
| EX-xxxW FLC4 AZDA | 1 PCS | 6.30*9.21*53.94 | 15 | 17 |
EX-xxxW-FLC2
EX-xxxW-FLC4
Oil and gas industry
• All petroleum production and refining
• Petroleum loading and transportation
• Petroleum storage and retail
• LNG industry
• All mining operations and service
Ocean, marine and aerospace field
• Ocean platform operation facilities
• Aerospace clean room and production
• Ocean vessel operations
Chemical industry
• All types of paint facilities
• Chemical production and storage
Metal treatment
• Steel and aluminum factories
• Pumping stations in any environment
• Metal smelting, foundry and fabrication
Food and alcohol industry
• Flour and fine particle production and storage
• Food and distilling production
• Alcohol industry
Other high humidity, high dust, high temperature, vapor locations.
Q1. What about the lead time?
A: 3-5 days for Sample preparing ,8-10 working days for mass production.
Q2. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
