Product Details:
|
| Material: | Copper-free Aluminum | Item Type: | Explosion- Proof Lights |
|---|---|---|---|
| Ip Rating: | 66 | Input Voltage(v): | AC100-277V/DC12-48V AC200-480V |
| Working Temperature(℃): | -40 - 60 | Warranty: | 5 Years |
| High Light: | Copper Free Aluminum explosion proof exit emergency lights,explosion proof exit emergency lights 20w,400W explosion proof emergency light |
||
20~400W Copper-free aluminum LED Explosion Proof Emergency alarm High Bay Fixtures W
Marking ATEX
II 2 G Ex db IIC T6 Gb
II 2 D Ex tb IIIC T80 Db IP66
Marking IECEx
Ex db IIC T6 Gb
Ex tb IIIC T80 Db IP66
Ambient Temperature:40°C to 60°C (-40°F to 140°F)
Ingress Protection: IP66
Impact Resistance (shock): IK10
Various materials and colors for lamp and amplifier are optional.
Diversity of mounting methods.
Low temperature applications to -40°C (-40°F) and high temperature up to 60°C (140°F).
With multi-functions, the flashlight can transform into different lights to suit different locations and needs.
5-year warranty.
Housing: Die-casting aluminum
Mounting Bracket: Aluminum
| Model | Max Wattage/Joule | Operating Voltage | Decibel |
| EX-WSLXxxJSxxdB-1 | 5J | AC220-240V | 100/120 |
| EX-WSLXxxWSxxdB-1 | 35W | AC220-240V/DC24V(18-36) | |
| EX-WSLXxxJSxxdB-2 | 5J | AC220-240V | |
| EX-WSLXxxWSxxdB-2 | 35W | AC220-240V/DC24V(18-36) | |
| EX-WSSxxdB-1 | 25W | AC220-240V/DC24V(18-36) | |
| EX-WSSxxdB-2 | 25w | AC220-240V/DC24V(18-36) | |
| EX-WSLXxxJ-3 | 5J | AC220-240V | Non |
| EX-WSLExxW-3 | 10W | AC220-240V/DC24V(18-36) |
Integrated with amplifier and light
Light
Amplifier and fast connection
| Model | Quantity/Carton | Packing Size(inch) | N.W(kg) | G.W(kg) |
| Amplifier | 1 PCS | 17.72*13.78*13.78 | 4.5 | 6.3 |
| Light A | 8 PCS | 17.72*13.78*13.78 | 16 | 18 |
| Light B C D | 1 PCS | 19.69*7.87*7.87 | 5 | 6.5 |
| Fast Connect | 1 PCS | 19.69*7.87*7.87 | 7 | 8.5 |
| Amplifier and Light | 1 PCS | 23.62*13.78*13.78 | 6 | 7.5 |
Bracket Mounting (Adjustable Angle):
Pole Mounting:
Hook and Fast Connection:
Junction Box Mounting:
| No. | Part | Mounting Type | Qty |
| 1 | Bracket | Bracket Mounting(Adjustable Angle | 1 |
| 2 | Junction Box | Junction Box Mounting | 1 |
| 3 | Straight Pipe | Pole Mounting | 1 |
| 4 | 90°Am | Junction Box Mounting | 1 |
| 5 | 25°Am | Junction Box Mounting | 1 |
Oil and gas industry
• All petroleum production and refining
• Petroleum loading and transportation
• Petroleum storage and retail
• LNG industry
• All mining operations and service
Ocean, marine and aerospace field
• Ocean platform operation facilities
• Aerospace clean room and production
• Ocean vessel operations
Food and alcohol industry
• Flour and fine particle production and storage
• Food and distilling production
• Alcohol industry
Chemical industry
• All types of paint facilities
• Chemical production and storage
Metal treatment
• Steel and aluminum factories
• Pumping stations in any environment
• Metal smelting, foundry and fabrication
Other high humidity, high dust, high temperature, vapor locations.
