Product Details:
|
| Material: | Copper-free Aluminum | Power: | 40,60,80,150 |
|---|---|---|---|
| Item Type: | Explosion- Proof Lights | Ip Rating: | 66 |
| Input Voltage(v): | AC100-277V/DC12-48V AC200-480V | Cri (ra>): | 70 |
| High Light: | 2200K Explosion Proof LED Canopy Light,2200K LED Canopy Light 100V,2200K 40W gas station canopy lights |
||
Explosion Proof CPA Series
Marking ATEX
II2 G Ex eb op is IIC T5/T6 GC
II2 D Ex op is tb IIIC T80° C Db
Marking IECEx
Ex eb op is IIC T5/T6 GC
Ex op is tb IIIC T80° C Db
UL Marking (North American)
UL1598, UL8750
Other Rating
IP 66
Oil and Gas industry
All petroleum production and refining
Petroleum loading and transportation
Petroleum storage and retail
LNG industry
All mining operations and service
Chemical industry
All types of paint facilities
Chemical production and storage
Ocean, marine and aerospace field
Ocean platform operation facilities and structure
Aerospace clean room and production
Ocean vessel operations
Metal treatment
Steel and aluminum factories
Pumping stations in any environment
Metal smelting, foundry and fabrication
Food and alcohol industry
Flour and fine particle production and storage
Food and distilling production
alcohol industry
Other high humidity, high dust, high temperature,vapor locations
Housing: copper free aluminum
Lens: glass
| Model | Wattage | CCT | Voltage | Lumens | Warranty | CRI |
| EX-40W CPAYZ | 40 | 2200K-7000K | AC100-277/DC 36V | 5600 | 5 years | >70 |
| EX-60W CPAYZ | 60 | 8400 | ||||
| EX-80W CPAYZ | 80 | 11200 | ||||
| EX-150W CPAYZ | 150 | 21000 |
“CPA”=Product code, “Y”=D or N:Dimmable or non-dimmable “Z”=CCT, from 2200-7000K
| Model | Quantity/Carton | Packing Size(mm) | Net Weight(kg) | Gross Weight(kg) |
| CPA | 2 | 460*470*310 | 8.23 | 9 |
Working Temperature: -40℃ ~ +60℃
High performance, most cost-effective LED canopy fixture in the market.
High Lumen per watt, tremendous flexibilitis in how you light your site.
Lumens availability can be up to 23,000 lumens.
Better and reasonable light distribution, more illumination on your dispensers.
Q1. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.
Q2. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available.
