Product Details:
|
| Power: | 600W | Lamp Luminous Efficiency(lm/w): | 170 |
|---|---|---|---|
| Cri (ra>): | 80 | Ip Rating: | IP67 |
| Working Lifetime(hour): | 50000 | Working Temperature(℃): | -30 - 55 |
| High Light: | LED Sport Court Light IP67,LED Sport Court Light 3000K,277V basketball court flood lights |
||
High lumen outpot TV broadcast standard intelligent LED Stadium light
Features:
▪ High lumen efficacy 170lm/w, energy saving 40%.
▪ High lumen SMD7070 LED chip, 40% and 10% stronger than SMD3030 and SMD5050 penetration respectively.
▪ Unique air convection radiator design provides superior ventilation efficiency
▪ Support TV broadcast standard
▪ Typhoon 17 resistance
▪ Beam Angle: 15°, 30°, 45°, 60° are available.
▪ Intelligent Zigbee controller, supports wireless on/off, dimming, color conversion, grouping, remote
control
▪ Various mounting brackets, 360 ° rotating bracket, round pole bracket, U-Bracket
Specifications:
Product Parameters
| Part Number | CODT-HM-600W-B |
| Wattage | 600W |
| Lumen Output | 102000lm |
| LED Chip | Lumileds 7070 |
| Luminous Efficacy | 170LM/W |
| LED Quantity | 144pcs |
| CCT | 3000K-6500K |
| CRI | ≥80 |
| Beam Angle | 15°/30°/45°/60° |
| IP Rating | IP67 |
| Working Temperature | -30℃ to +55℃ |
| Input Voltage | AC100-277V/347V/480V, 50/60Hz, ＞0.92 |
| Warranty | 7 years |
| Lifespan | ＞50,000hrs |
| Material | Die-casting Aluminum housing+PC lens |
| Size(MM) | L397*W369*H174 |
| Net Weight | 19.7KG |
Packing Information
| Part Number | N.G(KG) | G.W (KG) | Pcs/carton | Carton Size(CM) |
| CODT-HM600W-B | 19.7 | 26 | 1 | 52*50*39 |
Quick Details:
1. Typhoon 17resistance
Air convection structure can effffectively reduce wind load
2. Extraordinary Thermal Management
Unique air convection radiator design provides superior ventilation efffficiency
3. Various Beam Angle
15°/30°/45°/60° are optional
4. Laser sight
Efffficiently control the illuminating range of the luminaire to minimize installation costs
5. High light effffect
High lumen SMD7070 LED chip, 40% and 10% stronger than SMD3030 and SMD5050 penetration respectively
6. PLUG & PLAY Intelligent control
Intelligent Zigbee controller supports dimming, color conversion, grouping, remote control
Application:
AQ:
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 3-5 days for Sample preparing ,8-10 working days for mass production.
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.
