Product Details:
|
| Light Source: | LED | Ip Rating: | IP66 |
|---|---|---|---|
| Item Type: | Led Street Light | Warranty: | 5 Years |
| High Light: | IP66 integrated solar led street light,150w integrated solar led street light,100w integrated solar street lamp |
||
High luminary IP66 50w 100w 150w aluminum housing remote led street light L series
this high-efficiency street light with low energy consumption to provide you with outdoor comfort and safety. Aesthetic factors are taken into account in the design to enhance the cityscape. The technological innovations ensure that the luminaire can be used in harsh environments and keep maintenance costs to a minimum.
Patented private housing: The housing is made of integrated die-cast aluminum, which exhibits strong corrosion resistance. There is no heat sink on the back, so it is not easy for dust or bird droppings to accumulate, reducing maintenance costs. No tools are required to remove the cover of the light fixture. The sleek silver design enhances the cityscape and brings visual enjoyment to the neighborhood.
Precise optical design: Various types of light distributions are available: T2M/T3M/T4M. The professional anti-glare lens has high light transmittance and distributes soft and uniform light, which is comfortable for eyes.
Flexible installation methods: An array of accessories is attached for the customers to choose from, offering multiple mounting solutions. The angle can be adjusted within ±15°. The lamp pole can be installed horizontally or vertically.
Multiple intelligent control used to minimize of power consumption: 0-10V/1-10V Dimmable/DALI/Photocell Sensor.
Multiple drivers are considered to meet different projects needs: Philips/LiFud/Meanwell.
| Model NO. | ST-L1xxxW UXYZ | ST-L2xxxW UXYZ |
| Input Voltage | AC110-277V | AC110-277V |
| Power Consumption(±5%) | 50W/100W | 150W/200W/240W |
| Power Factor | >0.9 | >0.9 |
| Surge Protection | 10kV | 10kV |
| Intelligent Control | 0-10V/1 -10V Dimmable/Photocell/DALI | 0-10V/1 -10V Dimmable/Photocell/DALI |
| LED Chip | 3030/5050 | 3030/5050 |
| Driver | Philips/LiFud/Meanwell | Philips/LiFud/Meanwell |
| EPA | 0.15 Ft2 | 0.22 Ft2 |
| Efficency (±10%) | 130lm/W; 150lm/W | 1301 m/W; 150lm/W |
| CCT | 3000K/4000K/5000K | 3000 K/4000 K/5000 K |
| CRI | >70 | >70 |
| Beam Angle | T2M/T3M/T4M | T2M/T3M/T4M |
| IP Rating | IP66 | IP66 |
| IK Rating | IK09 | IK09 |
| Working Temperature | -40℃(-40°F) - +50℃(122°F) | -40℃(-40°F) - +50℃(122°F) |
| Lifespan | 50,000 Hours | 50,000 Hours |
| Warranty | 5 Years | 5 Years |
| Housing Material | ADC12 Aluminum | ADC12 Aluminum |
| Pole | 042-6Omm | 042-6Omm |
| Net Weight | 5.4kg(11.9lbs) | 7.8kg(17.2lbs) |
| Gross Weight | 6.7kg(14.8lbs) | 9.5kg(20.9lbs) |
| Product Dimension | 585x288x137mm(23.0x11.3x5.4inch) | 755x288x137mm(29.7x11.3x5.4inch) |
| Packing Size | 544x361 x184mm(21.4x14.2x7.2inch) | 730x362x203mm(28.7x14.3x8.0inch) |
PHOTOMETRIC DIAGRAMS
Specialized anti glare optical lens to deliver asymmetrical lighting solution T2M/T3M/T4M
APPLICATION AREAS
Urban & residential streets/bridges/bike & pedestrian path/railway stations & metros/car parks & squares
FAQ
Q1. How to proceed an order ?
Firstly, let us know your requirements or application.
Secondly, We quote according to your requirements or our suggestions.
Thirdly,customer confirms the samples and places deposit for formal order.
Fourthly, We arrange the production.
Q2: Do you offer guarantee for the products?
Yes, we offer 2-5 years warranty to our products.
Q3: How to deal with the faulty?
Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly,during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we
will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
